額定電壓 |
Nominal voltage |
200KV |
|
額定能量 |
Rated energy |
660J |
|
沖擊總電容 |
The impact of the total capacitance |
0.033μF(單臺脈沖電容器0.1μF/100KV，共3臺) |
|
負荷(分壓器)電容 |
Load (voltage divider)capacity |
500pf |
|
沖擊耐壓發生器效率 |
The efficiency of The impulse withstand voltage generator |
>85% |
|
衰減振蕩波起始電壓 |
Damped oscillatory wave initiation voltage |
≥40kV~200kV |
|
放電電壓 |
Discharge voltage |
≥40kV任意調節 |
|
放電頻率 |
Discharge frequency |
50Hz |
|
單次放電峰值誤差 |
Peak error of single discharge |
<1% |
|
充電電壓DC顯示誤差 |
Display error of DC charging voltage |
<1% |
|
諧振頻率 |
Resonant frequency |
10kHz~100kHz |
|
頻率測量誤差 |
The frequency measurement error |
<0.5% |
